Professional Manufacturer Paper Cutter (WD- 490R ) Hydraulic Paper Cutting Machine

Specifications


1. Max. Cutting Size: 490mm
2. Min. Cutting Size: 30mm
3. Cutting Thickness: 80mm
4. CE
5. Hydraulic Heavy duty Program Paper Cutter

New Design China Heavy duty Paper Cutter
Hydraulic Programmable paper cutter 490mm
Design with CE standard,
Heavy-duty stander, double hydraulic drive system,
European and American mark

WD-490R  Hydraulic Programing Paper Guillotines

Design with CE standard, front grating safety protection and back protection cover conform to safe system
Heavy-duty stander, symmetrical pressing paper function and double hydraulic drive system
Inclined cutting technology
Spin cutter with adjusting depth curve technology device
Adjustable gap of blade carrier technology with patented
Oscillating oil cylinder technology
Double orbit push paper function for guarantee of precision
Programmed circuit design, being able to save 99 group data with setting program at will
Opitical Cutting Line
Fashionable appearance design with patented

MODELWD-490R
Max. Cutting width:490mm
Max  Cutting length:490mm
Min. Cutting length:30mm
Max Cutting Thickness 80m
Cutting precision: ± 0.3mm
Pressing Paper Mode: Hydraulic
Cutting Paper Mode: Hydraulic
Pushing Paper Mode: Digital control
Program Yes
DisplayLiquid Crystal Display LCD
Power Supply AC220V(110V)± 10%50Hz60Hz, 2.5KW
Net Weight360kgs
Gross Weight400kgs
Machine Dimension(H*D*W)1370*125*940mm
